سیستم کنترل و مانیتورینگ اتاق سرور

The Honeywell ST3000 programmable temperature transmitter series offers affordable solutions for temperature monitoring programs. Compared to direct temperature sensor monitoring points, TT3000 series transmitters provide more accuracy, safety and reliability, while also reducing wiring costs. These transmitters automatically line up the temperature output signal limited by the upper range and the lower range specified by the user. In addition, the user can plan high or low -limit alarms to activate the sensor if the sensor fails.\r\n\r\n \r\n\r\nOutput \r\n\r\n4-20 mAh\r\nDigital communication mode\r\n\r\nPrecision\r\n4-20 MA: +/- 0.075 % of the domain of the gradient or the upper range, each\r\nDigital: +/- 0.0625 % of domain or +/- 0.125 % of reading, each less

Fresh Tracker 10 GPS Temperature and Humidity Data Logger | Recording Temperature, Humidity, Location, and Environmental Conditions The Fresh Tracker 10 locator thermometer from the brand Freshliance is a next-generation 4G network-based data logger that records temperature, humidity, light, vibration, and location data in real-time and syncs with a cloud platform. This product is a professional tool for cold chain control in pharmaceutical, food, biotech industries, and international transportation. The Fresh Tracker 10 SIM card temperature and humidity data logger navigator is powered by a high-capacity rechargeable battery with a lifespan of 120 days per full charge, 3.7 volts, 2000 mAh, rechargeable via USB Type-C cable. Fresh Tracker 10 Airplane Mode Temperature and Humidity Logger: The Airplane mode is also adjustable for air transport. When this mode is activated, the device automatically enters airplane mode at the preset start time. In this mode, the device only records data and does not upload data (the 4G module is turned off and no network signal is present). When the flight time ends, the device automatically exits this mode and after uploading past data, returns to normal operation. The Fresh Tracker 10 GPS SIM card temperature and humidity meter does not stop recording and storing data offline. Data that failed to upload during network outages will be automatically re-uploaded once the network is restored. In case of an alert, the user is notified via the LED indicator on the device and SMS/email from the platform or app. Equipment included in the Fresh Tracker-10 GPS SIM card temperature data logger pack: Data logger with a large 3.2*4.2 cm display Built-in rechargeable 3.2V 2A lithium battery Type-C connection cable QR code guide sheet External probe (optional) must be purchased separately Key Features of Fresh Tracker 10 Simultaneous data streaming to the cloud via 4G with 2G backup support Accurate temperature recording from –30 °C to +70 °C with ±0.5 °C accuracy and humidity from 0–100 %RH with ±3 %RH accuracy LCD display for current status, alerts, and instant reports along with LED indicator and cloud notifications LBS-based and optional GPS positioning technology for tracking shipment routes in app and map Storage of up to 30,000 data entries with upload capability when connection is available Rechargeable 3.7V battery with USB-C port and up to 120 days lifespan, supports charging during operation Adjustable flight mode, recording interval, start time, and alerts via app or cloud panel Technical Specifications and Capabilities of Fresh Tracker 10: Intelligent real-time monitoring of temperature, humidity, and location by sending live data to the cloud server using a 4G SIM card. Precise location display on map using GPS satellite positioning technology. Powerful internal sensor measuring temperature from -20 to +60 °C with ±0.5°C accuracy and relative humidity from 0 to 100% with ±3%RH accuracy. Support for optional external sensor: • Temperature only: range -30°C to +70°C with ±0.5°C accuracy • Temperature and humidity: temperature -30°C to +70°C with ±0.5°C F.S. accuracy and humidity 0 to 100%RH with ±3%RH accuracy External probe cable with a standard length of 2 meters for easy installation in various environments. Manual setting of data recording intervals, data upload times, and activation of airplane mode for different applications and international transport. Independent internal memory for each probe with storage capacity of 20,000 recorded data points even without network. Compatible with multiple platforms including mobile apps (Android/iOS) and web dashboard for management, viewing, and reporting. Support for 4G LTE Cat1 mobile network with fallback to 2G in areas without 4G signal. Internal rechargeable 3.7V lithium-ion battery with UN38.3 safety certification for international flight transport. Easy device installation using durable 3M adhesive tape or special hanger for wall or compartment mounting. Type-C charging input with DC 5V/2A for fast and reliable charging. Ability to receive full trip reports via USB Type-C as PDF or CSV files even without internet connection. Smart alert notifications via LED light, email, or SMS if temperature or humidity goes out of allowed range. Compact dimensions and portable design: 101 × 60 × 34 mm, weighing approximately 200 grams. Benefits of Using the Fresh Tracker-10 GPS Thermometer Professional data management and analysis via mobile app and cloud platform Downloadable PDF/CSV reports via USB button without internet connection Abnormal condition alerts via LED, email, or SMS Real-time location review and temperature and humidity charts Usable in air transport with flight mode activation Main Applications of the Fresh Tracker10 Cold Chain Data Logger: This device is excellent for cold chain quality control in: Transport and storage of vaccines, biological drugs, and medical samples Fresh food products, dairy, meat, and fruit Refrigerated, container, ground, and air transportation Temperature/humidity quality checks in laboratories and all logistics stages Carrier companies for precise vehicle location control Free Consultation for Purchasing Freshliance Tracker-10 GPS Data Logger For technical advice, pricing, setup, or ordering, contact us via: Email: info@dgtester.com WhatsApp: 0939 999 0062

Fnirsi Thermal Camera (Fnirsi) TDM-120P is a professional hybrid device that combines 120×90 pixel thermal imaging with a True RMS multimeter featuring 19999 counts. This tool speeds up and improves the accuracy of electrical and mechanical troubleshooting, providing real-time views of hot and cold spots alongside standard electrical measurements. The result of this combination is reduced downtime, enhanced safety, and data-driven decision-making in industrial and construction environments. In applications such as HVAC repairs, electrical panel monitoring, industrial equipment maintenance, leak detection, and automotive diagnostics, the TDM-120P—with a 25 Hz refresh rate, thermal sensitivity below 60mK, and automatic hot/cold spot tracking—detects faults earlier than traditional methods. Easy storage on an SD card and USB output also simplify documentation and sharing of test reports. Key Advantages and Features Smooth Thermal Imaging: Vanadium oxide sensor with 120×90 resolution and frame rate ≤25Hz for real-time temperature difference display and rapid anomaly detection Temperature Measurement Accuracy: Sensitivity <60mK, adjustable emissivity from 0.01 to 1, and temperature range from -20°C to 400°C with ±2°C or ±2% (maximum) accuracy True RMS Multimeter with 19999 Counts: Precise measurement of DC voltage up to 1000V and AC voltage up to 750V, along with resistance, capacitance, diode, and continuity tests, plus Data Hold and Min/Max display Quick Operation with 2.8-inch Touchscreen: 7 color palettes (Arctic, Hot Iron, Iron Red, Rainbow, Lava, Black Hot, White Hot) for clear visual differentiation Simple Storage and Reporting: One-click image saving to SD card and USB output for images and data to facilitate reporting and team sharing Portable and Safe Design: Compact body, Type-C charging, auto power-off settings, temperature unit selection, fixed center marker, and intelligent hot area tracking Technical Specifications Thermal Imaging Specifications Item Value Model TDM-120 / TDM-120P Detector Type Vanadium Oxide Infrared Resolution 120×90 Field of View (FOV) 50° Display 2.8-inch LCD Touchscreen Frame Rate ≤25Hz Color Palettes Arctic / Hot Iron / Iron Red / Rainbow / Lava / Black Hot / White Hot Temperature Range -4℉ to 752℉ (-20℃ to 400℃) Accuracy ±2℃ or ±2% (maximum) Temperature Unit ℃ / ℉ Temperature Tracking Center point display, automatic max/min tracking Temperature Alarm Supports high/low limit alarms Emissivity Adjustable 0.01 to 1 Languages Simplified Chinese / English Multimeter Specifications (TDM-120P only) Item Measurement Range Accuracy Counts and Measurement Method 19999 Count, True RMS — DC Voltage 1.9999V / 19.999V / 199.99V / 1000V ±(0.5%+3) AC Voltage 1.9999V / 19.999V / 199.99V / 750.0V ±(1%+3) Resistance 19.999MΩ / 1.9999MΩ / 199.99KΩ / 19.999KΩ ±(0.5%+3) Resistance 1.9999KΩ / 199.99Ω ±(2.0%+3) Capacitance 999.9μF / 99.99μF / 9.999μF / 999.9nF / 99.99nF / 9.999nF ±(2.0%+5) High Capacitance 9.999mF / 99.99mF ±(5.0%+20) Diode Test Supported — Continuity Test Supported — Data Features Data Hold, real-time Min/Max display — Additional Features Optimal Measurement Distance: 0.5 to 3 meters Storage: Plug & Play SD card Data Output: USB for transferring images and measurements Smart Settings: Auto power-off at 5/10/20 minutes/off, brightness adjustment, temperature unit switching Temperature Measurement Design: Fixed center temperature display, dual cursor (center + floating), hot area tracking Power Supply: Type-C charging Safety Note: Read the user manual and observe all warnings before use Practical Applications Electrical Maintenance: Identify loose connections, hot fuses, and unbalanced loads in electrical panels with automatic hot spot tracking while simultaneously measuring voltage and continuity with the multimeter for quick fault isolation. HVAC and Facility Service: Detect air duct leaks, clogged heat exchangers, and unbalanced fan coil operation with precise temperature mapping; then test electrical components like start capacitors on the same device. Construction and Safety: Reveal moisture intrusion behind walls, poor insulation, and thermal bridges non-destructively, providing image reports saved as files for clients or project inspectors. Automotive and Industrial Equipment: Track abnormal friction points in bearings, overheating in drives/inverters, and poor grounding connections; Min/Max capability offers real-time variation analysis for trend evaluation. Who Benefits Most Electrical and industrial repair technicians needing a single tool for thermal imaging and electrical measurement to reduce troubleshooting time and equipment load. HVAC contractors and building facility teams relying on clear documentation with thermal images alongside on-site electrical measurement verification. Maintenance and safety teams in factories requiring condition monitoring and early hot spot detection to prevent production downtime and accidents. Building and energy inspectors performing non-destructive insulation, moisture, and energy loss assessments with shareable reports. Comparison with TDM-120 Functionality: TDM-120P combines thermal imaging and True RMS multimeter; TDM-120 supports thermal imaging only. Efficiency: With TDM-120P, you can capture thermal maps and measure voltage/resistance/capacitance in one visit, simplifying workflow and reducing on-site time. Data-Driven Decisions: Integration of Min/Max, Data Hold, and USB/SD output in TDM-120P makes documentation and fault analysis more efficient than the thermal-only model. Getting Started and Best Practices For optimal accuracy, adjust emissivity according to surface material (0.01 to 1) and maintain a distance of 0.5 to 3 meters. Use different color palettes to enhance visual contrast based on the scene. Always read safety instructions in the user manual before use and set high/low temperature alarms according to site safety standards. Regularly save images to the SD card and export via USB to facilitate reporting and sharing findings.

The DPOF1204 oscilloscope is a digital phosphor four-channel oscilloscope designed for engineers, R&D teams, and production test units requiring deep analysis and high repeatability. Its integrated SoC + FPGA architecture offers 200 MHz bandwidth, sampling up to 1 GSa/s, and memory depth up to 14 Mpts alongside very low noise, enabling precise waveform reconstruction and long-term analysis without resolution loss. Beyond a general oscilloscope, the DPOF1204 provides FFT spectral analysis up to 1M-point, automatic measurements, event search, History/Sequence up to 90,000 records, and serial protocol decoding from I2C to CAN/LIN, making it a complete workstation for troubleshooting, validation, and production testing. Waveform capture rate up to 450,000 wfms/s in Sequence mode and advanced trigger system simplify capturing rare transients and complex conditions. Highlights and Advantages Four high-precision analog channels: simultaneous multi-line signal analysis for complex circuits 200 MHz bandwidth and sampling up to 1 GSa/s: reliable reconstruction of fast waveforms Very high capture rate: up to 450,000 wfms/s for capturing transient faults and low-repeat events Memory depth up to 14 Mpts: precise zoom and long-term analysis without losing details Noise floor 70–90 μVrms and sensitivity 500 μV/div: measuring low-level signals with better clarity Hardware and serial triggers >13 modes: accurate capture of complex conditions and protocol events Technical Details Item Specifications Model DPOF1204 Channels 4 analog channels Bandwidth 200 MHz Maximum Sampling Rate Two ADCs at 1 GSa/s (interleaved), 500 MSa/s per channel in 4CH Memory Depth Up to 14 Mpts (Interleaved), 7 Mpts (Non-interleaved) Waveform Capture Rate Up to 450,000 wfms/s (Sequence Mode) Triggers Edge, Slope, Pulse Width, Window, Runt, Interval, Dropout, Pattern, Video, Serial (I2C, SPI, UART, CAN, LIN) Bus Decoding I2C, SPI, UART, CAN, LIN FFT Processing up to 1M-point with peak detection and markers Measurements 38 automatic parameters + statistics, math, History Noise Floor ~70–90 μVrms Sensitivity Up to 500 μV/div Display 7-inch touch, 800×480 Interfaces USB Host, USB Device, LAN, Pass/Fail, Trigger Out Architecture Integrated SoC + FPGA Probes Four passive 200 MHz probes (FOP-200B) Weight ≈ 1036 grams Practical Applications Embedded and Mixed-Signal System Debugging: With I2C/SPI/UART decoding and protocol triggers, you can examine boot sequences, ACK/NACK errors, and transient interference alongside GPIO line amplitude and timing. History and event search speed up returning to problematic frames. Power Supply and Low-Level Signal Validation: 500 μV/div sensitivity and very low noise floor allow observing ripple, loop resonance, and switching noise. With built-in FFT, monitor harmonics and EMI near the source simultaneously, and with deep memory zoom, never miss transient details. Production Line Testing and Pass/Fail: Define patterns and tolerances, connect Pass/Fail and Trigger Out outputs to automation systems, and separate defective parts instantly with high capture rates. Sequence Mode with very low Dead-Time covers sporadic events. Who Benefits Most Electronics R&D Teams: For digital/analog design verification, timing measurements, and frequency analysis without auxiliary tools. Test and Production Engineers: For fast Pass/Fail tests, high waveform capture, and integration with automation lines via LAN/SCPI. Automotive and Industrial System Developers: For CAN/LIN analysis, transient interference, and monitoring power and sensor stability under varying environmental conditions. Why Choose This Model The DPOF1204 offers a balanced combination of 200 MHz bandwidth, deep memory, very high capture rate, and integrated analysis tools (FFT, serial protocols, History/Search). Its SoC+FPGA architecture and low noise floor enable repeatable accuracy in sensitive measurements, while the 7-inch touch screen and 18 one-click shortcuts increase daily work speed. For teams needing an all-in-one time-domain and frequency-domain tool, this device reduces cost and complexity. Integration and Remote Control Supporting USB, LAN, Pass/Fail, and Trigger Out, connecting to PCs, data logging systems, and production line automation is straightforward. SCPI commands and WebControl enable remote control, scripting, and monitoring; thus, you can standardize repetitive test scenarios and collect outputs over the network. Procurement Process and Included Items In the box: DPOF1204 device, four 200 MHz passive probes (FOP-200B), grounding wire, power adapter (US or EU plug), USB-A to USB-B cable, and user manual. Initial setup is quick, and with the touch interface, basic configuration can be done within minutes. Pricing and Availability Final price varies depending on additional probes, accessories, and warranty conditions. For quotes, up-to-date stock, and delivery times, contact the sales team or submit a price request. Offers for organizational orders and production projects are available.

Finesse Multimeter Model TMP610S – All Testing Tools in One Professional Device With the TMP610S, perform testing, troubleshooting, and calibration faster and more accurately. This 3-in-1 platform combines a True RMS multimeter, oscilloscope, and signal generator in a compact and portable body to meet your engineering, field repair, and laboratory testing needs. Key Features Integrated 3-in-1: True RMS multimeter + oscilloscope + signal generator in one compact device. 60,000 Count Accuracy: Stable measurements with μA and mV resolution for sensitive and board-level tests. 10MHz Oscilloscope with 48MSa/s Sampling: Instant waveform capture with AC/DC Coupling support for quick fault analysis. DDS Signal Generator up to 50kHz: 13 waveforms with frequency, amplitude, and duty cycle adjustment; ideal for testing, simulation, and calibration. Smart Bluetooth Connectivity (DMM only): Wireless monitoring, real-time data logging, and export via mobile app for fieldwork. Smart Auto-Scan Detection: Automatic identification of measurement type and range without manual switching; faster and easier operation. Advanced AC+DC Trend Analysis: Combined AC/DC display, trend tracking, Min/Max recording, and multi-point logging. 3.5-inch IPS Touchscreen Display: High resolution with day/night modes for readability and intuitive control. Wide Measurement Coverage: Voltage, current, resistance, capacitance, frequency, temperature, diode, and continuity. Portable Engineering Design: Type-C charging, 3000mAh battery, firmware upgrade support, waveform storage, and USB output. Suitable For Troubleshooting electronic boards and embedded systems Field repairs and industrial equipment servicing Research and educational laboratories Circuit development, validation, and calibration Why TMP610S? Saves space and cost with an integrated solution Speeds up work with Auto-Scan and smart data logging High accuracy and comprehensive signal insight with True RMS and AC+DC analysis Modern user experience with IPS touchscreen and app connectivity Choose the Finesse TMP610S multimeter now to enhance accuracy, speed, and efficiency in your testing and measurement projects.
