Plastic Nestable Pallet 120x100 Code 105
Price for bulk purchase over 100 units is 1,120,000 Tomans
Technical Introduction of the Raised and Nestable Plastic Pallet, Code 105
The code 105 plastic pallet by Azar Pallet is a lightweight and space-efficient logistics solution designed with standard dimensions of 120 by 100 centimeters. The main feature of this product is its "Nestable" capability, which allows for a significant reduction in pallet volume during storage or return transportation. This pallet is made from petrochemical raw materials and is suitable for transporting and storing light to medium loads in sanitary and industrial applications.
Technology and Design Explanation
The successful performance of the model 105 pallet is due to the combination of several technologies and key engineering principles:
Nestable Design Technology:
Instead of integrated runners, this pallet is designed with 9 conical feet. This design allows pallets to nest by the feet fitting into the empty spaces of the pallet below when stacked. The result of this technology is a volume reduction of up to 75% for empty pallets. This feature is especially a strategic advantage in reverse logistics (returning empty pallets) and in warehouses with limited space.
Raw Material Technology:
This product is made from first-grade High-Density Polyethylene (HDPE), directly sourced from petrochemical raw materials. Using virgin (non-recycled) materials guarantees the following:
Uniform molecular structure: resulting in predictable and consistent resistance to impact and pressure throughout the pallet.
Hygienic purity: a non-porous and chemically neutral surface makes this pallet fully suitable for contact with food and pharmaceutical packaging.
High chemical resistance: stability against a wide range of acids, bases, and industrial solvents.
Manufacturing Process:
This pallet is produced using the Single-Shot Injection Molding method. In this process, molten HDPE is injected under very high pressure into a precisely machined mold. This method produces a monoblock part without any nails, screws, or weak joints, maximizing product strength and durability.
Technical Specification Table
Technical Feature
Description and Values
Product Code
105
External Dimensions (cm)
Length: 120
Net Weight
9 kilograms (with ±2% production tolerance)
Raw Material
High-Density Polyethylene (HDPE) - Petrochemical Grade (First Class)
Static Load Capacity
1500 kilograms (1.5 tons) - Maximum load in stationary condition
Dynamic Load Capacity
1000 kilograms - Maximum load during forklift or pallet jack movement
Base Design
Raised (9 Feet) and Nestable - Optimized for storage space
Deck Design
Open-Deck - For reduced weight, ventilation, and ease of cleaning
Equipment Entry Type
Four-way Entry - Compatible with all forklifts and pallet jacks
Standard Colors
Blue - Made from first-grade raw materials
Container Loading Capacity
1500 units - Very high loading capacity due to nestable feature
Intended Use
Transport and storage of sanitary, industrial goods and light load warehouse organization
Technology-Based Advantages
Maximum space optimization: Nestable technology significantly reduces storage and transportation costs for empty pallets.
Lightweight and easy manual handling: The 7-kilogram weight of this pallet makes it easy and safe for manual handling.
High durability and long service life: The injection-molded monoblock structure and inherent HDPE resistance to moisture, pests, and chemicals extend its lifetime multiple times compared to wooden pallets.
Ideal for export: The low weight reduces air freight costs, and as a plastic product, it is exempt from quarantine and disinfection regulations (ISPM 15 standard).
Selection Guide
This pallet is suitable for users who:
Prioritize space saving. If you store or transport many empty pallets, this model is the best choice.
Handle light to medium loads (under 2000 kilograms). Such as textile industries, plastic parts, light carton packaging, and some pharmaceutical products.
Need a hygienic and washable solution.
Do not use rack shelving systems. (Raised pallets are not designed for direct placement on rack beams.)
Seek to reduce shipping costs, especially for exports.
For additional technical information, product datasheets, and price inquiries based on required volume, please contact our technical sales department.
