FNIRSI DPS-150 Portable and Programmable Power Supply | 150W 30V 5A
Key Features of the Standard DPS-150 Power Supply Product
High-Performance Output: 150W variable DC power supply, 30V and 5A with 0.01V and 0.001A accuracy.
Versatile Inputs: Supports PC inputs, fast chargers QC and PD, and DC adapters.
Multi-Purpose Connections: Compatible with 4mm banana plugs, U-shaped terminals, and copper wires.
Comprehensive Protection: Features 8 safety mechanisms including over-voltage, over-current, short-circuit, and over-temperature protection.
Four-Digit IPS Display: 2.8-inch screen with 90-degree rotation capability for numeric and curve display.
Compact and Portable Design: Small and lightweight, ideal for labs, repairs, and DIY projects.
Overview of the Standard DPS-150 Power Supply Product
The FNIRSI DPS-150 is a high-performance, adjustable, and programmable DC power supply that offers exceptional flexibility in power delivery. Supporting Type-C input and various power modes, it allows users to finely adjust output voltage (0-30V) and current (0-5A) with high precision. This power supply provides stable output, high efficiency, and is equipped with multiple protection mechanisms including OVP, OCP, and OTP. Its compact design, clear color display, and computer connectivity make it a powerful and efficient tool for various electronic applications.
Package Contents:
DSP-150 Host x1
2 Crocodile Clip Wires (Black and Red)
Micro USB Cable
1 User Manual
Packaging Box
Technical Specifications Table for the Standard DPS-150 Power Supply Product
Specification
Value
Brand
FNIRSI
Model
DPS-150
Input Voltage
DC 5.0V ~ 32V
Input Current
100mA - 5A
Input Methods
PD fast charger, QC fast charger, power bank, DC adapter
Output Voltage
0 ~ 30V
Output Current
0 ~ 5A
Output Power
0 - 150W
Operating Environment
0℃ - 40℃
Load Regulation
0.49%
Full Load Efficiency
96.30%
Display
2.8 inch (320x240)
Weight
Approximately 178 grams
Dimensions
106x76x28 mm
Over Voltage Protection (OVP)
Supported
Over Current Protection (OCP)
Supported
Under Voltage Protection (UVP)
Supported
Over Power Protection (OPP)
Supported
Over Temperature Protection (OTP)
Supported
Reverse Input Protection
Supported
Reverse Output Protection
Supported
Short Circuit Protection
Supported
Computer Software
Supported
Firmware Update
Supported
Full Introduction Section for the Standard DPS-150 Power Supply Product
Expert Review of the FNIRSI DPS-150 Programmable Power Supply - Standard
The FNIRSI DPS-150 is a step-down (buck) DC-DC power module that, with its modern design and advanced features, meets the needs of electronics professionals, repairers, and enthusiasts. Its standout feature is the flexibility in input sources; you can power it using the latest fast chargers based on PD and QC protocols, powerful power banks, or standard DC adapters. This capability makes the DPS-150 a truly portable power supply usable anywhere.
With a 150W output power and precise voltage and current adjustment, this device is ideal for powering and testing various electronic circuits—from sensitive microcontrollers and sensors to small DC motors and LED modules. Its large color display not only shows numerical values with 4-digit accuracy but also displays voltage and current curves, which is very useful for monitoring load behavior. The presence of 8 protective layers ensures device and connected circuit safety under unexpected conditions.
Strengths:
Input Flexibility: Compatibility with various modern (Type-C) and traditional (DC Jack) power sources.
High Accuracy and Stability: Precise voltage and current adjustment with output ripple under 20mV.
Comprehensive Protection: Multiple safety mechanisms offer peace of mind against damage to the device and circuits.
Excellent User Interface: Large, clear color display with curve visualization.
Computer Connectivity: Ability to control and monitor through desktop software.
Limitations:
Step-Down Operation: This device is a buck converter, meaning the input voltage must always be higher than the desired output voltage.
No Power Adapter Included: In the standard package, no input power adapter is provided; users need to procure a suitable adapter separately as per their needs.
Buying Guide for the FNIRSI DPS-150 Standard Handheld Power Supply
Specify Your Input Power Source: Before purchase, ensure you have a suitable power source (DC adapter, PD/QC charger) with adequate voltage and current to supply your maximum required power.
Pay Attention to Buck Nature: This device cannot increase voltage. For example, to obtain 30V output, you need an input above 30V (up to 32V).
Application: This device is very suitable for circuit testing, electronic repairs, student projects, and powering sensitive equipment.
Target Customers of the Standard DPS-150 Power Supply Product
Mobile, laptop, and electronic board repair technicians
Electronics enthusiasts and DIY project hobbyists
Students and electrical & electronics engineering laboratories
Embedded systems and microcontroller developers
Quality control and testing professionals in small production lines
Users in need of precise and portable power supplies for field work
Robotics and automation industry professionals
