Product Introduction
The SWM-20 portable spot welding machine is a powerful, lightweight, and portable tool that utilizes Dual-Pulse welding technology to create stable, clean, and high-quality joints. In addition to professional welding performance, this device is equipped with a 5000mAh power bank to charge USB devices when needed.
The 2.4-inch color TFT display shows real-time information such as voltage, device temperature, and welding parameters, while the rotary encoder knob allows quick and precise parameter adjustments. These features make the SWM-20 a suitable choice for professional users and DIY project enthusiasts.
Features
Powerful 1200 Amp Output
With a maximum current of 1200 amps, it enables strong, uniform, and reliable welds on various metals.
Dual-Pulse Welding Technology
First pulse: removes the oxide layer on the metal surface
Second pulse: creates a clean, strong, and stable weld
This technology improves joint quality and reduces the chance of sparks or sheet burning.
Compatible with Various Metals (0.1 to 0.5 mm)
Capable of welding:
Nickel-plated steel up to 0.4 mm thickness
Steel up to 0.5 mm thickness
Pure nickel up to 0.25 mm thickness
Iron up to 0.3 mm thickness
Copper and nickel-plated copper up to 0.1 mm thickness
Over 10,000 Fine Adjustment Levels
Allows very precise output power adjustment according to metal type and thickness for optimal weld quality.
Full Welding Parameter Adjustment
Adjustable parameters include:
Preheat time
Welding pulse
Pulse interval
Number of continuous weld spots
2.4-inch Color TFT Display
Real-time display of important information such as:
Battery voltage
Device temperature
Welding settings
Operational status
Easy Adjustment with Rotary Encoder
The rotary encoder knob makes parameter adjustments fast, precise, and very convenient.
Two Grade A Lithium Batteries with 5000mAh Capacity
Using high-quality cells ensures the device:
Has higher output power
Provides more stable performance
Can be used for longer durations
Up to 1500 Weld Spots per Full Charge
A single full charge allows approximately 1500 welding operations, suitable for professional use and DIY projects.
2-in-1 Design
Besides spot welding, this device can also be used as a USB power bank with 5V/2.1A output.
Fast Charging via USB Type-C
Charging input:
5V / 2.1A
Enables fast charging and reduces waiting time.
Pure Copper Welding Tips
Welding tips with 99.9% pure copper have the following features:
Very high electrical conductivity
Good heat transfer
Longer durability
Easy replacement
Lightweight and Portable Design
Compact dimensions and suitable weight make it easy to carry for on-site projects or mobile repairs.
8-Fold Intelligent Protection System
The device includes protective circuits for:
Over-temperature protection
Under-voltage protection
Overcharge protection
Over-discharge protection
Short circuit protection
Output voltage stabilization
Low temperature protection
Shock protection
Auto Power-Off
Auto power-off time can be set from 0 to 99 minutes to enhance safety and save energy.
Firmware Update Support
Firmware can be updated in the future via the USB Type-C port.
Applications
Suitable for:
Lithium battery pack assembly
Electric bicycle battery repair
Mobile phone battery replacement
Rechargeable tool battery repair
Electronic projects
DIY projects
Repair workshops
Technical Specifications
Specification
Value
Battery Capacity
5000mAh
Charging Voltage
5V / 2.1A
USB Output
5V / 2.1A
Weldable Materials
Nickel, Iron, Steel
Weldable Thickness
0.1 to 0.5 mm
Maximum Welding Current
1200A
Default Modes
4 combined levels
Package Contents
SWM-20 Spot Welder
Welding Tips
Spare Tip Heads
USB Type-C Cable
Nickel Tape
User Manual
