FNIRSI DPS-150 Portable and Programmable Power Supply | 150W 30V 5A
Key Features of the Standard DPS-150 Power Supply Product
High-performance output: Variable DC power supply 150 watts, 30 volts, and 5 amps with 0.01V and 0.001A accuracy.
Diverse inputs: Supports PC inputs, QC and PD fast chargers, and DC adapters.
Multi-purpose connections: Compatible with 4mm banana plugs, U-shaped terminals, and copper wires.
Comprehensive protection: Equipped with 8 safety mechanisms including over-voltage, over-current, short circuit, and over-temperature protections.
Four-digit IPS display: 2.8-inch screen with 90-degree rotation capability for numeric and curve display.
Compact and portable design: Small and lightweight, ideal for labs, repairs, and DIY projects.
Overview of the Standard DPS-150 Power Supply Product
The FNIRSI DPS-150 is a high-performance, adjustable, and programmable DC power supply that offers exceptional flexibility in power delivery. Supported by Type-C input and multiple power modes, it allows users to precisely set output voltage (0-30 volts) and current (0-5 amps). This power supply features stable output, high efficiency, and multiple protection mechanisms including OVP, OCP, and OTP. Its compact design, clear color display, and computer connectivity transform this device into a powerful and efficient tool for various electronic applications.
Standard:
DSP-150 Host x1
Crocodile clip wires x2 (black and red)
Micro USB cable
User manual x1
Packaging box
Technical Specifications Table for Standard DPS-150 Power Supply Product
Specification
Value
Brand
FNIRSI
Model
DPS-150
Input Voltage
DC 5.0V ~ 32V
Input Current
100mA - 5A
Input Methods
PD fast charger, QC fast charger, power bank, DC adapter
Output Voltage
0 ~ 30V
Output Current
0 ~ 5A
Output Power
0 - 150W
Operating Environment
0℃ - 40℃
Load Regulation
0.49%
Full Load Efficiency
96.30%
Display
2.8 inch (320x240)
Weight
Approximately 178 grams
Dimensions
106x76x28 mm
Over Voltage Protection (OVP)
Supported
Over Current Protection (OCP)
Supported
Under Voltage Protection (UVP)
Supported
Over Power Protection (OPP)
Supported
Over Temperature Protection (OTP)
Supported
Reverse Input Protection
Supported
Reverse Output Protection
Supported
Short Circuit Protection
Supported
Computer Software
Supported
Firmware Update
Supported
Complete Introduction Section for Standard DPS-150 Power Supply Product
Professional Review of the Programmable FNIRSI DPS-150 Standard Power Supply
The FNIRSI DPS-150 power supply is a DC-to-DC step-down (Buck) module designed with modern features to meet the needs of electronics professionals, repair technicians, and enthusiasts. Its standout feature is flexibility in input source; it can be powered by the latest PD and QC fast chargers, robust power banks, or standard DC adapters. This makes the DPS-150 a truly portable power supply usable anywhere.
With 150 watts output power and precise voltage and current adjustment capabilities, it is ideal for powering and testing various electronic circuits, from microcontrollers and sensitive sensors to small DC motors and LED modules. Its large color display not only shows numerical values with 4-digit precision but also plots voltage and current graphs, useful for load behavior monitoring. The presence of 8 layers of protection ensures device and circuit safety under unexpected conditions.
Strengths:
Input flexibility: Compatible with modern (Type-C) and traditional (DC Jack) power sources.
High accuracy and stability: Precise voltage and current setting with output ripple less than 20mV.
Complete protection: Multiple safety mechanisms provide peace of mind against device and circuit damage.
Excellent user interface: Large, clear color display with curve visualization.
Computer connectivity: Control and monitoring possible via desktop software.
Limitations:
Step-down operation: This device is a Buck converter, meaning the input voltage must always be higher than the desired output voltage.
No included adapter: The standard package lacks an input power adapter; users must obtain it separately as needed.
Buying Guide for the FNIRSI DPS-150 Handheld Power Supply Standard
Specify your input power source: Before purchase, ensure you have an appropriate power source (DC adapter, PD/QC charger) with sufficient voltage and current to supply your maximum power requirements.
Note step-down nature: The device cannot increase voltage. For example, to output 30 volts, you need an input voltage above 30 volts (up to 32 volts).
Usage: Ideal for circuit testing, electronic repairs, student projects, and powering sensitive equipment.
Target Customers for the Standard DPS-150 Power Supply Product
Mobile, laptop, and electronic board repair technicians
Electronics enthusiasts and DIY project hobbyists
Students and electrical engineering laboratories
Embedded system and microcontroller developers
Quality control and testing specialists in small production lines
Users needing a precise, portable power supply for fieldwork
Robotics and automation professionals
