Semikron, IXYS, EUPEC IGBT Seller

Providing design, manufacturing, sales, and specialized repair services for medium voltage drives (MV Drive) and electronic cards of the Brazilian WEG brand series MVW01, MVW3000, and CFW-11, including the following cards: 1- MVC3: Main control 2- MVC4: User interface control 3- FOI 3, 4: It converts electrical signals into optical signals and vice versa 4- PIC2: Power supplies for the electronics, internal use digital inputs and output relays 5- EBA, EBB, EBC: Optional function expansion boards 6- Fieldbus: Optional network communication boards 7- ISOY/ISOZ: Signal feedback boards, they measure medium voltages or temperatures and send the information via optical signals (1 channel) 8- ISOX: (ISOX.00, ISOX.01, ISOX.12) Signal feedback boards, they measure medium voltages or temperatures and send the information via optical signals (1 channel) 9- PS24: Electronics power supply: input: 220 Vac 3 - or 220 Vac 1 - output: 15 Vdc 10- PS1/PS1S: Isolated power supply: input: 22 Vac 1 - (PST) 220 Vac 1 - (PSTS) output: 15Vdc 11- HVM: It indicates that the DC link is energized 12- 1SD210F2: Gate drivers 13- 1SP0335: Gate drivers 14- PLC2: PLC expansion board - optional 15- RSSI: Absolute encoder interface - optional 16- HMI Cables 17- 1SD210F2: IGBT Gate Driver Board 18- ISO31161-65: DC/DC Power Supply Module for IGBT Driver Board 19- CROWBAR Module: CROWBAR Protection Module 20- RC900: Electrical Board for CTW900 EXC. Rectifier 21- IC900B: Control Board for CTW900 EXX. Rectifier 22- ISOC2.00: Voltage Measurement Module 23- IPS1: Interface board for CFW-11 24- PSB1: Switched mode power supply for CFW-11 25- CIM1: Interface with the control for CFW-11 26- CRG9: Gate resistor boards, set of IGBTs Modules gate resistor board 27- GDB5: Gate driver boards, modules and sensors for the output voltage and output current. WEG Medium Voltage Drive VSI: Voltage Source Inverter VFD (Variable Frequency Drive) CHB (Cascade H Bridge) NPC (Neutral Point Clamp) Power Arm Power Cell WEG MVW01 WEG MVW3000

Programmable Power Supply 150V 30A 3000W OWH67030-150S by OWON The high power OWH67030-150-S power supply by OWON is one of the most advanced DC laboratory power supplies with high power of 3000 watts at 150 volts and 30 amps, single-channel, offering precise programming of voltage, current, and time to the user. These devices allow defining and executing a 100-step profile (Step List) and can simulate your desired output curve by repeating various cycles. This model provides an output range of 0 to 150 volts and 0 to 30 amps, and thanks to the resolution of 10 millivolts / 1 milliampere and a fast recovery time ≤5 milliseconds, it is an ideal choice for testing power equipment, chargers, DC-DC converters, drivers, and even MPPT testing of solar inverters. The OWON OWH67030-150-S is designed with a sturdy metal body and a 3.9-inch TFT color display. This display allows numerical and graphical viewing of voltage, current, and power values. On the front panel, there is a rotary knob, numeric keypad, and large +/– output terminals, while the rear section includes USB, RS485, CAN, and optional LAN ports, Analog/Dry Contact terminals, Remote Sense output, and a cooling fan. Outstanding Features of the OWON OWH67030-150S 150V 30A Power Supply Full programmability up to 100 steps including voltage, current, event time, and cycle count settings Ability to select Curve/Load mode for advanced testing Equipped with an internal discharge circuit for safety during shutdown and to prevent residual high voltage Can be used in parallel (up to 3 units) or series (up to 2 units) configurations with maximum output power of 1200 watts, 300 volts, and 120 amps No need for recalibration in parallel mode Different Models of OWON OWH67 Series Power Supplies Output Current Output Voltage Output Power Power Supply Model 30A 80V 1200W OWH67012-80 20A 150V 1200W OWH67012-150 10A 300V 1200W OWH67012-300 20A 150V 2000W OWH67020-150 10A 300V 2000W OWH67020-300 10A 600V 2000W OWH67020-600 30A 150V 3000W OWH67030-150 15A 300V 3000W OWH67030-300 10A 600V 3000W OWH67030-600 OWH67030: Base model with fundamental features OWH670-L: Equipped with LAN communication port for remote control and network sharing OWH670-S: Equipped with P-V simulation mode to reproduce current–voltage (IV) curves of solar panels under various environmental conditions including temperature, irradiation, shading, and degradation In PV Mode, light intensity varies between 0 to 1000 W/m² allowing real efficiency testing of panels. This feature is highly valuable for testing and validating grid-tied inverters, energy storage systems, and MPPT tracking. Design Features and 19-Inch Standard Rack The OWH67 series power supplies are designed to be portable with a sturdy handle and standard size. Support for the 19-inch U2 ½ standard rack enhances efficiency and ease of use in laboratory and industrial environments. Benefits of using the standard rack include: Optimal space management: Installing multiple devices in minimal space Standardization: Easy compatibility with other equipment and simplified upgrades or replacements Better cooling: Proper airflow to prevent temperature rise Quick access: Ease of inspection, repair, or relocation of devices Safety and durability: Robust structure to support equipment weight and reduce damage risk Technical Specifications of OWH67030-150S Power Supply Feature Value Rated Power 3000 Watts Output 0–150V-0 / 30A Resolution 10mV / 1mA Setting Accuracy ≤0.05%±20mV (V) / ≤0.1%±30mA (I) Noise/Ripple Voltage ≤150mVp-p / Current ≤50mArms Recovery Time ≤5ms (10→100% load) Display 3.9-inch Color TFT LIST Programming Up to 100 steps (1ms–28h) Interfaces USB, RS485, CAN, LAN (optional), DB25 Dimensions/Weight 215.2×87.6×468mm 6.8KG AC Input 85–265Vac, 45–65Hz Special Feature Solar Panel Simulator (PV Simulator) in -S version Summary The OWON OWH67 series is an ideal choice for research, industrial applications, and electronic equipment testing. From 100-step programming and solar panel simulation to series and parallel operation capabilities, these power supplies meet a wide range of laboratory and testing needs. For more detailed information, you can refer to the product catalog or contact our experts at DigiTester.

Barous Sanat Company is a supplier and importer of various types of heat tracing cables. Heat tracing cables are available in different types, and this company is capable of supplying all kinds of these heat tracing cables. Among these types, self-regulating or constant wattage cables can be mentioned. Some of the reputable brands for which Barous Sanat Company is the main supplier include: BARTEC HEAT TRACE RAYCHEM QUINTEX THERMON CHROMALOX ELTHERM What are the uses of the heat tracing system? Preventing freezing Preventing solidification Maintaining viscosity Preventing condensation formation Preventing moisture formation (at low temperatures) Preventing moisture formation (at high temperatures) Sterilization It is worth mentioning that all auxiliary equipment for heat tracing systems can be supplied by this company. For consultation and inquiries about availability and pricing, you can contact us via phone, WhatsApp, or Eitaa. 0939-90-70-860

The CNTD CM-1704 short tongue micro switch with pulley is one of the widely used models in the CM series by CNTD, designed for position detection, motion control, and precise command transmission in industrial control circuits. This micro switch features a short lever with a plastic pulley that enhances smooth movement, reduces friction, and increases mechanical service life.

A connector is used to connect electrical or electronic components to each other. Connectors usually include pins, jacks, and sockets that enable safe and quick connection and disconnection of two components. They are used in various industries such as electronics, automotive, and mechanical industries. The function of a connector is to establish a connection between two electrical or electronic components. They can provide data transfer, power transmission, wire and cable connections, as well as a fast and reliable connection between two components. Connectors are available in different types, sizes, and standards to meet the diverse needs of industries. Connector materials may be made from various substances such as plastic, metal, aluminum, fiber optics, etc. The choice of material depends on factors like usage type, working environment, operating temperature, and physical and electrical requirements. Selecting the connector material depends on the different needs of industries and applications. For example, in some cases, connectors with high resistance to heat or corrosion are required, while in other cases, connectors with low weight and good electrical insulation properties are needed. Connectors or sockets are important components in connecting and transferring information and energy between devices and electronic parts. They act as physical interfaces between different components and can transmit information through electricity and various methods. The applications of connectors are very broad and they are used in many industries, including electronics, automotive, mobile phones, computers, and medical equipment. They serve as communication interfaces between different parts in these industries. The company is active in the production of various industrial and telecommunications connectors. This company is recognized as one of the leading companies in industrial and telecommunications connectors. Its products hold various certifications such as KIB Certification, UL 14001 Certification, ISO 9001, and ISO. Types of twist connectors, locking connectors, and telecommunications system connectors are included in this company's product portfolio. Shayarad Sanat, as the official representative of Youngjin connectors from South Korea, serves the production and industry of this homeland.

Technical Specifications: Input Voltage 220 Volt AC Output Voltage 24 Volt AC Output Power 150 Volt Ampere (VA) Operating Frequency 50/60 Hertz Structure Single-phase and isolated Physical Specifications: Length 105 millimeters Width 65 millimeters Height 88 millimeters (excluding terminals) *Minimal heat generated due to core iron losses *Copper winding with standard design *Continuous operation and true amperage *Price: Due to fluctuations in raw material prices, please inquire by phone. Boland Nazar brand in design and manufacturing of various custom transformers Website: https://bolandnazar.com Contact Number: 09128685166

Radman Engineering Consulting and Technical Services (RADMAN) With nearly two decades of engineering and technical experience in electrical, control systems, PLC, and instrumentation Active in oil and gas, steel, mining, chemical and pharmaceutical industries, automotive industries, and food industries projects Provider of engineering and technical services in electrical, industrial automation, PLC, and instrumentation Engineering, design, manufacturing, installation, implementation, commissioning, maintenance and support, training Design and implementation of electrical and automation for factories and industrial plants Boiler safety Automation and electrical systems for industrial engine rooms and utilities Automation of industrial chillers Electrical and automation of production lines and industrial machinery Holding specialized and practical training courses in electrical, industrial automation, PLC, and instrumentation Workshop phone: 02645367231 Mobile phone: 09128596624 and 09114972012 Website: www.linkedin.com/in/radman-engineering Email: Radman.etsc@gmail.com Workshop address: Alborz Province - Nazarabad

Product Introduction The SWM-20 portable spot welder is a powerful, lightweight, and portable tool that uses Dual-Pulse welding technology to create stable, clean, and high-quality joints. In addition to professional welding performance, this device is equipped with a 5000mAh power bank to charge USB devices when needed. The 2.4-inch color TFT display shows real-time information such as voltage, device temperature, and welding parameters, while the rotary encoder knob allows quick and precise parameter adjustments. These features make the SWM-20 an ideal choice for professional users and DIY enthusiasts. Features Powerful 1200 Amp Output With a maximum current of 1200 amps, it enables strong, uniform, and reliable welds on various metals. Dual-Pulse Welding Technology First pulse: Removes the oxide layer on the metal surface Second pulse: Creates a clean, strong, and stable weld This technology improves joint quality and reduces the chance of sparks or sheet burning. Compatible with Various Metals (0.1 to 0.5 mm) Capable of welding: Nickel-plated steel up to 0.4 mm thickness Steel up to 0.5 mm thickness Pure nickel up to 0.25 mm thickness Iron up to 0.3 mm thickness Copper and nickel-plated copper up to 0.1 mm thickness Over 10,000 Fine Adjustment Levels Allows extremely precise output power adjustment according to metal type and thickness to achieve the best weld quality. Full Welding Parameter Adjustment Adjustable settings include: Preheat time Welding pulse Pulse interval Number of continuous weld spots 2.4-Inch Color TFT Display Real-time display of important information such as: Battery voltage Device temperature Welding settings Operational status Easy Adjustment with Rotary Encoder The rotary encoder knob makes parameter adjustments fast, precise, and very convenient. Two Grade A Lithium Batteries with 5000mAh Capacity Using high-quality cells ensures the device: Delivers higher output power Provides more stable performance Has longer usage time Up to 1500 Weld Spots per Charge One full charge allows approximately 1500 welding operations, suitable for professional use and DIY projects. 2-in-1 Design Besides spot welding, the device can also be used as a USB power bank with 5V/2.1A output. Fast Charging via USB Type-C Charging input: 5V / 2.1A Enables fast charging and reduces waiting time. Pure Copper Welding Tips Welding tips with 99.9% pure copper tips feature: Very high electrical conductivity Good heat transfer Longer durability Easy replacement Lightweight and Portable Design Compact dimensions and suitable weight make it easy to carry for on-site projects or mobile repairs. 8-Fold Intelligent Protection System The device includes the following protective circuits: Over-temperature protection Under-voltage protection Overcharge protection Over-discharge protection Short-circuit protection Output voltage stabilization Low-temperature protection Shock protection Auto Power-Off Adjustable auto power-off time from 0 to 99 minutes to enhance safety and save energy. Firmware Update Support Firmware can be updated in the future via the USB Type-C port. Applications Suitable for: Lithium battery pack assembly Electric bike battery repair Mobile phone battery replacement Rechargeable tool battery repair Electronic projects DIY projects Repair workshops Technical Specifications Specification Value Battery Capacity 5000mAh Charging Voltage 5V / 2.1A USB Output 5V / 2.1A Weldable Materials Nickel, Iron, Steel Weldable Thickness 0.1 to 0.5 mm Max Welding Current 1200A Default Modes 4 combined levels Package Contents SWM-20 Spot Welder Welding Tips Spare Tip Heads USB Type-C Cable Nickel Tape User Manual
