SMS control with TI644 4-channel programmable timer

SMS control with TI644 4-channel programmable timer

The Saba 644 device is a remote control system equipped with an internal clock, which allows you to control your equipment by setting the clock in addition to the ability to control it by texting or ringing. The easy operation of the device has made it usable by all people. The use of this device is very diverse, and the settings of the device are very simple, and the settings can be programmed and saved on the device through SMS or phone communication.

Capabilities and features :
\ The ability to control all outputs by setting 99 time commands so that the electrical appliances connected to the device turn off and on at the times you determine in a day or on all days of the week. (For example, every Monday, the pump should be turned on at 14:00 and turned off at 15:00.)
The ability to define 25 dates and times (calendar) so that the outputs are turned on or off on the specified date. (For example, on 12/10/1402 at 10:20 a device that is connected to one of the outputs should be turned on or off.)
The ability to define the duration of switching on and the duration of switching off the outputs and its automatic repetition until the output Turn the target on and off. (For example, the air conditioning device connected to the output is turned on for one hour and turned off for two hours and this is repeated automatically.)
The possibility of setting the time for the commands sent to the outputs until the desired output time is automatically changed. to give (For example, in the message that you give the order to turn on the pump, you also specify the pump shutdown time so that the pump will automatically turn off at the specified time.)
Control and management of devices and equipment without being present at the site. by mobile phone (by SMS or single ring and phone call) r\nCan be used in all places covered by the mobile phone network around the world
Support for First Mobile, Irancell and Rightel SIM cards
Has 4 real seven amp relay outputs
Has 6 isolated inputs with industrial capabilities , security and ...
The possibility of naming all inputs, outputs and ... for better remembering by the user
Sending a message and making a voice call and playing a warning siren if the input is triggered\r \nThe possibility of independent management of sending warnings for each of the inputs
The ability to set the timer mode for the outputs
The possibility of turning on and off the output by stimulating the input
The possibility of turning on output one on a timer from 1 to 5 minutes After triggering the input, it is possible to maintain the status of the outputs by disconnecting and connecting the power, it is possible to announce the disconnection and disconnection of the power with a message, to make a call and play an alarm (if the battery is installed), it is possible to install a temperature and humidity sensor. Digital that has the ability to track and monitor temperature and humidity. (For example, you set the temperature range to 25-40 and the humidity range to 50-70. If the humidity or temperature goes out of the allowed range, the device will send you an SMS or phone alert {monitoring}. You can also instruct the device to do both Temperature and humidity clock for sh
