ارائه خدمات طراحی، ساخت، فروش و تعمیرات تخصصی درایو های ولتاژ متوسط (MV Drive) و کارتهای الکترونیکی برند WEG برزیل سری MVW01، MVW3000 و CFW-11 شامل کارتهای زیر:
1- MVC3: Main control
2- MVC4: User interface control
3- FOI 3, 4: It converts electrical signals into optical signal and vice versa
4- PIC2: Power supplies for the electronics, internal use digital inputs and output relays
5- EBA, EBB, EBC: Optional function expansion boards
6- Fieldbus: Optional network communication boards
7- ISOY/ISOZ: Signal feedback boards, they measure medium voltages or temperatures and send
the information via optical signals (1 channel)
8- ISOX: (ISOX.00, ISOX.01, ISOX.12) Signal feedback boards, they measure medium voltages or temperatures and send
the information via optical signals (1 channel)
9- PS24: Electronics power supply: input: 220 Vac 3 - or 220 Vac 1 -output: 15 Vdc
10- PS1/PS1S: Isolated power supply: input: 22 Vac 1 - (PST) 220 Vac 1 - (PSTS) output: 15Vdc
11- HVM: It indicates that the DC link is energized
12- 1SD210F2: Gate drivers
13- 1SP0335: Gate drivers
14- PLC2: PLC expansion board - optional
15- RSSI: Absolute encoder interface - optional
16- HMI Cables
17- 1SD210F2: IGBT Gate Driver Board
18- ISO31161-65: DC/DC Power Supply Module for IGBT Driver Board
19- CROWBAR Module: CROWBAR Protection Module
20- RC900: Electrical Board for CTW900 EXC. Rectifier
21- IC900B: Control Board for CTW900 EXX. Rectifier
22- ISOC2.00: Voltage Measurement Module
23- IPS1: Interface board for CFw-11
24- PSB1: Switched mode power supply mode power supply for CFw-11
25- CIM1: Interface with the control for CFw-11
26- CRG9: Gate resistor boards, set of IGBTs Modules gate resistor board
27- GDB5: Gate driver boards, modules and sensors for the output voltage and output current.
WEG Medium Voltage Drive
VSI: Voltage Source Inverter
VFD (variable Frequency Drive)
CHB (Cascade H Bridge)
NPC (Neutral Point Clamp)
Power Arm
Power cell
WEG MVW01
WEG MVW3000
تهران
