Product name: What are industrial valves?

Description:
One of the widely used types of equipment in the industry is valves. These equipments optimize the performance conditions of fluid transmission lines. Valves can be installed in the upstream, midstream and downstream sections. These equipments have different types and are used for different purposes. In the continuation of this article, we will introduce the types of industrial valves, standards, applications and other related matters.

What are industrial valves?
These valves are tools used in the industry to cut off, connect and control the flow of liquids or gases in pipelines. In some situations, there are valves that open and close automatically to prevent unexpected incidents. A quality valve or valve passes fluids with minimal resistance and pressure drop. Sometimes this tool is used to change the flow direction or to change the pressure and temperature. Therefore, valves are important and widely used equipment in various industries such as oil and gas. The main components of valves include body, cap or bonnet, conduit, yoke, cap, shaft, disc, seat, trim and actuator.

Technical specifications of industrial valves
Valves have different technical specifications such as body material, type of function (manual or automatic), application and appearance. Size, mechanical movement, flow of fluids, valve ratio and pressure drop are other technical specifications that should be considered when choosing valves. In the following, we will examine the features of this industrial equipment.

Features of industrial valves
These equipments have a wide range of features that will be different according to their type and function. For example, valves that are used to transfer liquids such as water have a stainless steel body. In some systems where there is a need to prevent accidents, valves operate automatically. In general, valves in the industry are made of cast iron, brass, bronze, steel, carbon steel and stainless steel. Among them, brass valves and cast iron valves are more commonly used. The connection type of cast iron valves is flange and the connection type of brass valves is rib.

Industrial valve standard
In the field of valves used in the industry, 22 international standards are common. Among these standards, four are more applicable. The API 591 standard examines such things as the tensile strength of the valve stem, body, and sealing. Another widely used standard is the API 598 standard, which deals with valve inspection, inspection location, pressure test and how to apply test pressure. ISO 52008, API 6D and BS 6755 can be mentioned among other valve testing and inspection standards. API 599 standard for cone valves and API 600 standard are used in oil, gas and petrochemical industry. In addition to these international standards, two standards, IGS and IPS, can be mentioned, which are more suited to Iran's conditions.
